A6798S
Code: A6798S
Category: Alternators
Manufacturer: Denso
Supplier: As-pl
: 104211-3174
STANDARD LINE
Brand new AS-PL Alternator
Size a: 33.00 mm
Size b: 20.00 mm
Size c: 51.00 mm
Amp.: 100 A
D.1: 11.00
D.2: M8x1.25
D.3: M10x1.25
Pulley: AFP
L.1: 168.00 mm
Plug: PL_4000
G: 6
O.d.1: 55.00 mm
Voltage: 12 v
Reference number
| Code | Manufacturer | ||||||||||
| UD102092A | As-pl | ||||||||||
| UD102753A | As-pl | ||||||||||
| 104211-3171 | Denso | ||||||||||
| 104211-3174 | Denso | ||||||||||
| 27060-37150 | Toyota | ||||||||||
| |||||||||||
| 90-29-5932 | Wilson | ||||||||||
Usage
| Brand | Model | Type | Year | Note |
| Scion | iM 1.8 | 01.2016-12.2016 | ||
| TOYOTA | COROLLA Estate (_E16_) 1.8 (ZRE162G) | 2ZR-FAE | 05.2012- | |
| TOYOTA | COROLLA RUMION (_E15_) 1.8 (ZRE152) | 2ZR-FAE | 01.2013- | |
| TOYOTA | COROLLA RUMION (_E15_) 1.8 (ZRE152) | 2ZR-FAE | 09.2007- | |
| TOYOTA | COROLLA RUMION (_E15_) 1.8 4WD (ZRE154) | 2ZR-FAE | 09.2007- | |
| TOYOTA | COROLLA Saloon (_E15_) 1.8 (ZRE142) | 2ZR-FAE | 08.2008-04.2012 | |
| TOYOTA | COROLLA Saloon (_E15_) 1.8 (ZRE142) | 2ZR-FAE | 10.2006-05.2012 | |
| TOYOTA | COROLLA Saloon (_E15_) 1.8 4WD (ZRE144) | 2ZR-FAE | 08.2007-05.2012 | |
| TOYOTA | COROLLA Saloon (_E18_, ZRE1_) 1.8 VVTi (ZRE170) | 2ZR-FAE | 09.2013-12.2014 |
