S0970S
Code: S0970S
Category: Starters
Manufacturer: Bosch
Supplier: As-pl
: 0001194006
STANDARD LINE
Brand new AS-PL Starter motor
Size a: 64.00 mm
Size b: 23.00 mm
C.1: 11.00 mm
C.2: M10x1.25 mm
L.1: 195.00 mm
No./teeth: 13
No./mount. holes: 2
No./mount. holes with thread: 1
O.1: 126.00 mm
Power: 1.40 kW
Rotation: CW
Voltage: 12 v
Reference number
| Code | Manufacturer | |
| UD102561S | As-pl | |
| SBO059 | Autoteam | |
| SBO072 | Autoteam | |
| 0001194006 | Bosch | |
| 0001194064 | Bosch | |
| F002GC0066 | Bosch | |
| S101355 | BTS Turbo | |
| CST10059GS | Casco | |
| STR041N | Dipasport | |
| 318242132 | Dri | |
| 12546 | Eai | |
| 25-5512 | Elstock | |
| 109517 | Farcom | |
| 51975680 | Fiat | |
| 10010059OV | Itab Automotive | |
| 256789B | Kuhner | |
| 256789S | Kuhner | |
| LRS04350 | Lucas | |
| LRS4350 | Lucas | |
| 5010054G | Meat & Doria | |
| 8214168 | Powermax | |
| 88214168 | Powermax | |
| IR1237 | Protech | |
| 500.414.132.280 | Psh | |
| 500.414.132.281 | Psh | |
| S143.895 | Psh | |
| 20401950OE | Sando | |
| S12BH0882 | Sidat | |
| S12BH0882A2 | Sidat | |
| 6010059.1 | SIOM | |
| MAV120590 | SIOM | |
| FI9087 | Snra | |
| STX201489R | Stardax | |
| 546ST21 | Startcar | |
| ST02969 | Tmi | |
| 31174-OS | Wai / Transpo | |
| 31174N | Wai / Transpo |
Usage
| Brand | Model | Type | Year | Note |
| ALFA ROMEO | TONALE (965_) 1.3 Hybrid Q4 | 46337540 | 03.2022- | |
| ALFA ROMEO | TONALE (965_) 1.3 Hybrid Q4 | 46337540 | 03.2022- | |
| FIAT | 500 (312_) 1.0 Mild Hybrid (312.AYD1B) | 46341162 | 01.2020- | |
| FIAT | 500 C (312_) 1.0 Mild Hybrid (312.AYD1B) | 46341162 | 01.2020- | |
| FIAT | PANDA (312_, 319_) 1.0 Mild Hybrid (312.PYD1B) | 46341162 | 01.2020- | |
| LANCIA | YPSILON (312_) 1.0 Mild Hybrid (312) | 46341162 | 03.2020- |
